Lenze Motors And Gearboxes

NPSDAPL Lenze Motors And Gearboxes

Lenze Motors

One thing is certain: you need to be able to rely on your motors. They convert electrical energy into mechanical energy and, therefore, are the central drive component in your machine. Since they play such an important part, we offer you motors with optimum drive behavior and application-oriented options. A fast and reliable solution.

Servo motors
Inverter-operated three-phase AC motors
Mains-operated three-phase AC motors

Industrial geared motors in the power range up to 55 kW. Lenze m300 Smart Motors have rated torque from 1.75 to 5 Nm. Lenze 3 phase asynchronous motors available in efficiency classes IE1, IE2 and IE3 accotrding to ErP directive. Available from 0.06 to 55 kW. Lenze inverter optimised MF asynchronous motors available from 0.55 to 22 kW.

Smart Motors

SMART asynchronous geared motors are drive solutions for chain and roller conveyors with payloads up to 5200 kg.

Integrated motor and equipment contactor and brake resistor without complicated wiring.

Standard control inputs, speed selections significantly reducing product variables.

SMART-MOTORS

LENZE MF, IE1 MD, IE2 MH & IE3 M550 SERIES 3 PHASE ASYNCHRONOUS MOTORS

Three-phase AC motors suitable for a wide range of tasks and covering a power range from 0.12 to 45 kW.

These motors come in different efficiency classes and can be used for the versions required for open or closed-loop controlled inverter operation.

easy-essentials

SERVO MOTORS TYPE MCS, M850 AND MCM

Lenze synchronous servo motors are designed for all applications requiring precision and dynamic performance. Synchronous motors available from 0.5 to 200 Nm.

Compact designs are suitable for positioning, robotics, packaging and handling system applications. Smooth surfaces suitable for food industry applications.

easy-essentials

SERVO MOTORS TYPE MCA, MQA AND SDS

Lenze asynchronous servo motors for heavy duty applications requiring precisely controlled motion. Asynchronous Servo motors available from 2 to 1100 Nm.

Typical applications in cable, winding, paper converting industries with high dynamic loads and precision Motion Control.

easy-essentials

Gearboxes

One single motor alone is not a universal solution to all applications. After all, many applications require low speed and high torque, and your machine may need a right-angle drive.

The robust, efficient industrial gearboxes from Lenze can handle even the toughest of machine tasks. If you require couplings, locking bushes or other drive elements for your machine, you are sure to find precisely the right products for your requirements in our scalable product portfolio.

Planetary gearboxes
Shaft-mounted helical gearboxes, helical gearboxes and bevel gearboxes

PLANETARY GEARED MOTORS G700, MPR AND MPG

Lenze planetary gearbox solutions typically used in dynamic servo applications requiring compact and high precision.

Gear units can be supplied with ratio’s from 3 to 512, torque range up to 800 Nm and back-lash < 1 arc minute.

easy-essentials

HELICAL GEARED MOTORS G500-H AND GST

Lenze robust helical geared motors are characterised by high permissible radial forces, closely stepped speed reduction ratios and a low backlash.

Available with Lenze Smart Motor m300, three-phase AC motors and inverter-optimised MF three-phase AC motors. With synchronous servo motors and asynchronous servo motors in the power range from 0.25 to 38.4 kW.

easy-essentials

SHAFT MOUNTED HELICAL GEARED MOTORS G500-S AND GFL

Lenze slimline shaft-mounted helical geared motors are characterised by high permissible radial forces, closely stepped ratios and a low backlash.

Available with Lenze Smart Motor m300, three-phase AC motors and inverter-optimised MF three-phase AC motors. With synchronous servo motors and asynchronous servo motors in the power range from 0.25 to 38.4 kW.

easy-essentials

BEVEL GEARED MOTORS G500-B AND GKR

Lenze efficient bevel geared motors are characterised by high permissible radial forces, closely stepped ratios and a low backlash.

Available with Lenze Smart Motor m300, three-phase AC motors and inverter-optimised MF three-phase AC motors. With synchronous servo motors and asynchronous servo motors in the power range from 0.25 to 38.4 kW.

easy-essentials
